SCALANCE SC-600 Web Based Management (WBM)
Configuration Manual, 10/2021, C79000-G8976-C475-03
353
Exchange of configuration data with STEP7
6.1 Exchange of configuration data with STEP 7
Basic/Professional using a file
You use the two file types "RunningSINEMAConfig" and "SINEMAConfig" ("System >
Load&Save > HTTP/TFTP/SFTP") to exchange configuration data between a device
(WBM) and STEP7 Basic/Professional using a file. The export/import of a file via STEP 7
Basic/Professional is described below.
Exporting configuration data via STEP 7 Basic/Professional
To export configuration data via STEP 7 Basic/Professional, follow these steps:
1. Open the relevant STEP 7 project in STEP 7 Basic/Professional.
2. Open the project view.
3. Open the network view or the topology view.
4. Open the Hardware catalog.
5. In the hardware catalog, navigate to the device with the relevant article number.
6. Select the desired device with a mouse click.
7. Set the matching firmware version via the drop-down list of the hardware catalog.
8. Drag-and-drop the device to the network view or to the topology view.
9. Select the device in the network view on in the topology view.
10. Configure the device in the Inspector window under "Properties > General".
11. In the Inspector window, navigate to the "Management" parameter under "Properties >
General".
12. In the parameter group "Load / save file", click the "Save to file" button.
13. Select a storage location for the file.
14. Assign a name for the file.
15. Click the "Save" button.
The "Save configuration file" dialog opens.
16. Assign a password for the encryption of the file.
Note
You need this password when you load the file to a device via the WBM.
17. Click the "OK" button.
