Siemens SIMATIC NET SCALANCE W M766 Series

Description of the device
4.5 Accessories
SCALANCE WxM766
22 Operating Instructions, 03/2022, C79000-G8976-C617-03
4.5.1 Installation
Component
Description
Article number
Mounting adapter
DIN rail
Adapter for mounting on a 35mm DIN
rail according to DIN EN 50 022
6GK5798-8MF00-0AA1
Angle adapter
90° angle adapter for rail mounting,
only in conjunction with SCALANCE
MUM856-1, WAM/ WUM766-1;
Scope of delivery: Bracket with
mounting rail adapter for 35 mm
standard mounting rail, fixing screws
6GK5798-8MF00-0AB1
4.5.2 CLP
Component
Description
Article number
CLP
Configuration License
PLUG
Exchangeable storage medium for
saving configuration data
SCALANCE CLP 2GB
6GK1900-0UB00-0AA0
SCALANCE CLP EEC 2GB
6GK1900-0UQ00-0AA0
CLP iFeatures
Exchangeable storage medium for
saving configuration data and enabling
iFeatures
SCALANCE CLP 2GB W700 AP
iFeatures
6GK5907-8UA00-0AA0
SCALANCE CLP 2GB W700 Client
iFeatures
6GK5907-4UA00-0AA0
