Siemens SIMATIC NET SCALANCE W M766 Series

Description of the device
4.5 Accessories
SCALANCE WxM766
28 Operating Instructions, 03/2022, C79000-G8976-C617-03
Flexible connecting cable IWLAN QMA/N-Connect male/female
Adapter cable for connecting a MIMO antenna with QMA connectors to the flexible
connecting cables; preassembled with one QMA male and one N-Connect female
connector; scope of delivery 3 units:
Length
Article number
1 m
6XV1875-5JH10
For railway applications, the following connecting cable is available, scope of delivery 1
unit:
Length
Article number
1 m
6XV1875-5VH10
4.5.6.2 Lightning protection
Component
Description
Article number
LP798-1N
Lighting protector with N/N
female/female connector with gas
discharge technology
6GK5798-2LP00-2AA6
LP798-2N
Lighting protector with N/N
female/female connector with quarter
wave technology
6GK5798-2LP10-2AA6
4.5.6.3 Terminating resistor
Component
Description
Article number
TI795-1N
Electrical connector N-Connect, male
Pack of 1
6GK5795-1TN00-1AA0
4.5.6.4 Cabinet feedthrough
Component
Description
Article number
IE M12 Panel Feedthrough
4 x 2
Cabinet feedthrough for conversion
from M12 connector technology (X-
coded, IP65/67) to RJ-45 connector
technology (X-coded, IP20)
pack of 5
6GK1901-0DM40-2AA5
N-Connect/N-Connect
Female/Female Panel
Feedthrough
Cabinet feedthrough for wall
thicknesses up to 4.5 mm, two N-
Connect female connectors
6GK5798-2PP00-2AA6
N-Connect/SMA
Female/Female Panel
Feedthrough
Panel feedthrough for wall thicknesses
up to a maximum of 5.5 mm, two N-
Connect/SMA female connectors.
6GK5798-0PT00-2AA0
