Siemens SIMATIC NET SCALANCE W M766 Series

Technical specifications
SCALANCE WxM766
Operating Instructions, 03/2022, C79000-G8976-C617-03
73
Technical specifications
Digital output
Quantity
1
Design
M12 socket, A-coded
Rated voltage
24 V DC
safety extra-low voltage (SELV)
Max. input voltage
30 V DC
safety extra-low voltage (SELV)
Fuse
0.5 A
Max. cable length
< 3 m
Cables should be routed in pairs
Properties
Output isolated from electronics
Permissible ambient conditions
Ambient temperature
During
operation
Non-EEC variant
-30 °C ... +60 °C
EEC variant
-30 ℃ to +75 ℃
During storage
-40 ℃ to +85 ℃
During transportation
-40 ℃ to +85 ℃
Relative humidity
During operation
≤ 90% at 25 °C, no condensation
Operating altitude
During operation
≤ 2000 m above sea level
• Non EEC variant max. 60 °C
• EEC variant max. 75 °C
> 2000 m above sea level
• Only EEC variant max. 70 °C
Contaminant concentration
According to ISA-S71.04.-2013 Class G3
Degree of pollution
2
Degree of protection
IP65
Dimensions and weight
Dimensions
W x H x D
150 x 179.4 x 45 mm
Weight
1.1 kg
Installation options
Direct
Wall mounting
With additional adapter
Mounting on a DIN rail
Mean time between failure (MTBF)
at 40 °C ambient temperature
24 years
