Description of the device
3.4 Accessories
SCALANCE W774-1 /W734-1
20 Operating Instructions, 07/2020, C79000-G8976-C325-14
3.4.1.2 Antennas
Note
When you select an antenna, keep in
mind the national approvals for your device.
You will find more detailed information in Wireless approvals
(
https://www.siemens.com/wireless-approvals).
The SCALANCE W1788-2IA uses internal omni antennas (3/4 dBi at 2.4 GHz or 5 GHz).
Type
Properties
Article number
IWLAN RCoax Antenna
ANT792-4DN
RCoax helical antenna with circular polari-
zation for RCoax systems, 4 Bi, 2.4 GHz,
IP65, N-Connector female.
6GK5792-4DN00-0AA6
ANT792-6MN
Omnidirectional antenna, mast/wall
mounting, 6 dBi 2.4 GHz, IP67, N-Connect
female
6GK5792-6MN00-0AA6
ANT792-8DN
Directional antenna, mast/wall mounting,
14 dBi 2.4 GHz, IP32, N-Connect female
6GK5792-8DN00-0AA6
IWLAN RCoax
ANT793-4MN
RCoax λ4 antenna with vertical polariza-
tion for RCoax systems, 6 dBi, 5 GHz, IP65,
N-Connector female
6GK5793-4MN00-0AA6
ANT793-6DG
Wide angle antenna, mast/wall mounting,
9 dBi 5 GHz, IP66/67, 2 x N-Connect fe-
male
6GK5793-6DG00-0AA0
ANT793-8DJ
Directional antenna, mast/wall mounting,
18 dBi 5 GHz, IP67, 2 x N-Connect female
6GK5793-8DJ00-0AA0
ANT793-8DK
Directional antenna, mast/wall mounting,
23 dBi 5 GHz, 2 x N-Connect female
6GK5793-8DK00-0AA0
ANT793-8DL
Directional antenna vertical-horizontal
polarized, 5 GHz, 14dBi, IP66, 2xN-
Connect female
6GK5793-8DL00-0AA0
ANT793-8DP
Directional antenna, mast/wall mounting,
13 / 13.5 dBi 4.9 GHz and 5 GHz, N-
Connect female
This antenna is not available in Korea
6GK5793-8DP00-0AA0
ANT795-4MA
Omnidirectional antenna, directly on the
device, 3/5 dBi 2.4 GHz and 5 GHz, IP30,
R-SMA connector male for direct installa-
tion on the device, angle connector ad-
justable 0° - 180°.
6GK5795-4MA00-0AA3
ANT795-4MB
Omnidirectional antenna, 2/3 dBi 2.4 GHz
and 5 GHz, IP30, R-SMA connector female
for direct mounting on the device, angle
connector adjustable 0° to 90°.
6GK5795-4MB00-0Ax0
ANT795-4MC
Omnidirectional antenna, 3/5 dBi, 2.4 GHz
and 5 GHz, IP65, N-Connect male for di-
rect installation on the device, straight
connector.
6GK5795-4MC00-0AA3
