6.2 Spring-loaded terminal
The following gure shows the individual components of a spring-loaded terminal:
① Wire inlet For connecting the wire
② Button For releasing the wire
③ Test contact For measuring the voltage
Connecting up
6.2 Spring-loaded terminal
SCALANCE XM-400
56 Operating Instructions, 03/2021, C79000-G8976-C306-10
