31
To set segment
10 (°C)
Temperature from 95°C to 110°C
Maximum speed
hh : mm : ss
Durat. 0 : 0 : 0
Wait duration : OFF
N1
Channel 1
Control : ON
Wait set point : ON
Max speed : ON
Set point :110.00 °C
Grad. : 0.00 °C/min
Near set : 1,00 °C
N2
N3
To carry out the segment at maximum
speed
OP2605-140
to save the programmed segment
Save segment : SAVE
N4
EDIT PROGRAM
< ESC > Prev. menu
Segment N. 11
To set segment
10 (% RH)
Humidity - - - - not controlled
Wait for this number to appear.
10
Leave everything switched OFF as humidity is not controlled in this temperature range
• Press
repeatedly
SHIFT
ENTER
This page is visualized
Save segment : OFF
Total segment : 0
Confirm progr : OFF
When this page is visualized, if the previ-
ously described operations have been
carried out, the segment has been saved
and therefore must not be saved again.
Move on to the next step.
WARNING!
If you have accidentally saved the same segment twice, correct the number on this page.
