Technical specifications
A.3 Signal boards
Easy Book
106 Manual, 05/2009, A5E02486774-01
A.3 Signal boards
General SB 1223 DI 2x24VDC, DQ 2x24VDC SB 1223 AQ 1x12bit
Order number 6ES7 223-0BD30-0XB0 6ES7 232-4HA30-0XB0
Dimensions (W x H x D) 38 x 62 x 21 (mm) 38 x 62 x 21 (mm)
Weight 40 grams 40 grams
Power dissipation 1.0 W 1.5 W
Current consumption (SM Bus) 50 mA 15 mA
Current consumption (24 VDC) 4 mA / Input used 40 mA (no load)
Inputs/outputs 2 inputs (IEC Type 1 sink)
2 outputs (solid state - MOSFET)
1 output
(voltage or current)
Digital inputs SB 1223 DI 2x24VDC, DQ 2x24VDC
Number and type of inputs
(Number of inputs on simultaneously)
IEC Type 1 sink: 2 inputs
(2)
Rated voltage 24 VDC at 4 mA, nominal
Continuous permissible voltage 30 VDC, max.
Surge voltage 35 VDC for 0.5 sec.
Logic 1 signal (min.)
Logic 0 signal (max.)
15 VDC at 2.5 mA
5 VDC at 1 mA
HSC clock input rates (max.) 20 kHz (15 to 30 VDC); 30 kHz (15 to 26 VDC)
Isolation (field side to logic)
Isolation groups
500 VAC for 1 minute
1
Filter times 0.2, 0.4, 0.8, 1.6, 3.2, 6.4, and 12.8 ms
Selectable in groups of 2
Cable length (meters) 500 shielded, 300 unshielded
Digital Outputs SB 1223 DI 2x24VDC, DQ 2x24VDC
Number and type of outputs
(Number of outputs on simultaneously)
Solid state - MOSFET: 2 outputs
(2)
Voltage range 20.4 to 28.8 VDC
Logic 1 signal at max. current 20 VDC min.
Logic 0 signal with 10K Ω load 0.1 VDC max.
Current (max.) 0.5 A
Lamp load 5 W
On state contact resistance 0.6 Ω max.
Leakage current per point 10 μA max.
Pulse Train Output rate 20 KHz max., 2 Hz min.
Surge current 5 A for 100 ms max.
Overload protection No
Isolation (field side to logic)
Isolation groups
500 VAC for 1 minute
1
Currents per common 1 A
