Introducing the flexible and powerful S7-1200
1.3 Mounting dimensions and clearance requirements
Easy Book
12 Manual, 05/2009, A5E02486774-01
PP
PP
ི
ཱི
ཱི
ཱི
ཱི
PP
ཱ
ཱི
① Side view ③ Vertical installation
② Horizontal installation ④ Clearance area
Always consider the following guidelines when planning your
installation:
• Separate the devices from heat, high voltage, and electrical
noise.
• Provide adequate clearance for cooling and wiring. A 25 mm
thermal zone must be provided above and below the unit for free
air circulation.
Refer to the
S7-1200 System Manual
for specific requirements and
guidelines for installation.
