4 Configuration and Project Engineering
4.1 Creating the project configuration
SINAMICS G120 as a Speed Axis on the S7-1500
V1.0a, Entry ID: 78788716
16
Copyright  Siemens AG 2013 All rights reserved
No. Action Picture
3. Create a new project and
assign a name (e.g.,
“G120_at_S7-1500_TO”).
Inserting the SIMATIC S7-1500
4. Double-click on “Add new
device”.
5. 1. Select “Controller”.
2. Select the desired CPU.
3. Then click on “OK”.
1
2
3
