Ethernet Gateway for SIMATIC MPI/PROFIBUS Driver
GP-Pro EX Device/PLC Connection Manual
10
IP Address
Input the IP address of Gateway/Module. Search the adapter in the network and click the
[Search].
Port No. Display the port number of Gateway/Module.
Speed Set the communication speed of MPI/PROFIBUS network.
Local Node Set the node number of Display in MPI/PROFIBUS network.
Highest Node Number Set the maximum node number of MPI/PROFIBUS network.
• Refer to the GP-Pro EX Reference Manual for Indirect Device.
Cf. GP-Pro EX Reference Manual "Changing the Device/PLC at Runtime (Indirect
Device)"
Setup Items Setup Description
To Next Page
