Ethernet Gateway for SIMATIC MPI/PROFIBUS Driver
GP-Pro EX Device/PLC Connection Manual
14
Device Setting
To display the setting screen, touch [Device/PLC Settings] from [Peripheral Equipment Settings]. Touch the
External Device you want to set from the displayed list, and touch [Device].
Setup Items Setup Description
Device/PLC Name
Select the External Device to set. The device name is the title of the External Device set with
GP-Pro EX.(Initial value [PLC1])
Series Display the series name of External Device.
Target Node
Use an integer from 0 to 126 to enter the node No. of the External Device. Be sure to set the
node No. within the range which does not exceed the value set in [Highest Node Number] of
[Communication Settings].
To Next Page
