Siemens SIMATIC S7-200 Series User Manual

Ethernet Gateway for SIMATIC MPI/PROFIBUS Driver
GP-Pro EX Device/PLC Connection Manual
3
1 System Configuration
The system configuration in the case when the External Device of Siemens AG and the Display are connected is
shown.
Series CPU Link I/F
Communication
Method
Setting Example
SIMATIC
S7-200 Series
CPU214
CPU215
CPU216
CPU221
CPU222
CPU224
CPU226
Port 0/1 on the CPU unit Ethernet (TCP)
"Setting Example 1"
(page 7)
SIMATIC
S7-300 Series
CPU312IFM
CPU313
CPU314
CPU314IFM
CPU315
CPU315-2 DP
CPU316
CPU316-2 DP
CPU318-2
MPI port on the CPU
unit
Ethernet (TCP)
"Setting Example 1"
(page 7)
SIMATIC
S7-400 Series
CPU412-1
CPU412-2 DP
CPU413-1
CPU413-2 DP
CPU414-1
CPU414-2 DP
CPU414-3 DP
CPU416-1
CPU416-2 DP
CPU416-3 DP
CPU417-4
MPI port on the CPU
unit
Ethernet (TCP)
"Setting Example 1"
(page 7)

Siemens SIMATIC S7-200 Series Specifications

General

Communication	PROFIBUS DP
Protocols	PROFIBUS-DP
Configuration	STEP 7 Micro/WIN programming software
Communication Ports	RS-485 port
Power Supply	24 V DC or 120/230 V AC
Operating Temperature	0°C to 55°C
