First steps for the project
2.2 Configuring the device hardware
SIRIUS Motor Starter PCS 7 Library "V7.1+SP2"/ "V8 Migration V8.0+SP1"
14 Getting Started, 08/2013, A5E02897539020A/RS-AA/005
2.2 Configuring the device hardware
Introduction
The PCS 7 wizard has created the following components:
● A SIMATIC 400 station
● A SIMATIC PC station
● A master data library
Now add additional hardware modules to the project from the Hardware Catalog in
HW Config.
Procedure for configuring devices from the hardware catalog
Table 2- 2 Steps
Step Action
1
• Select the SIMATIC 400 station in the component view of the SIMATIC Manager.
• Select the "Edit > Open Object" menu command.
The HW Config opens.
