SIEMENS AG PRODAVE S7
Toolbox for Data Link PGs/PCs to SIMATIC S7
6
2.4 Connection of PG/PC to PLC
2.4.1 Driver under Windows 95/98/NT
The PG/PC may be connected to the PLC by means of the following
components:
o CP 5611 PCI-Card
o CP 5511 PCMCIA-Card
o CP 5411 ISA-Card
o MPI-ISA-Card or MPI-ISA on Board (PG 720/740/760, PC RI45,25,FI25)
o COM 1/2 via PC-Adaptor
PC S7-300/400/M7/C7
MPI-ISA MPI-interface
CP5411/5511/5611 S7-200
PPI-interface
PC S7-300/400/M7/C7
COM1/2 PC-Adaptor MPI-interface
Installation and set-up of the required hardware is carried out via the STEP7-
Tool PG/PC interface parameterisation, which is available in the system after
successful installation.
