Page #11 background image
Performance features
2
2.1 Smart Panels
Introduction
The following table provides assistance in estimating whether a specific project is still within
the performance features of the HMI device.
The stated maximum values are not additive. We cannot guarantee proper functioning of
configurations that make full use of all system limits on the HMI devices.
In
addition to the specified limits, the transfer time of process values must be observed during
serial communication. A low baud rate may have the result that process values are not updated.
Smart Panels
Smart 700
Smart 1000
Smart 700 IE
Smart 1000 IE
Variables
Number of variables in the project 500 800
Number of PowerTags -- --
Number of elements per array 100 100
Number of local variables -- --
Alarms
Number of alarm classes 32 32
Number of discrete alarms 200 200
Number of analog alarms 15 15
Character length of an alarm 80 80
Number of process values per alarm 8 8
Size of the alarm buffer 256 256
Number of queued alarm events 64 64
Images
Number of screens 50 100
Number of variables per screen 30 100
Number of complex objects per screen 5 5
Recipes
Number of recipes 5 5
Number of elements per recipe 20 20
User data length in bytes per data record -- --
Smart Panels
System Manual, 06/2012, 11
