3.2 Opening the Device
84 Digital Fault Recorder, SIMEAS R/SIMEAS R-PMU, Maintenance Manual
E50417-H1074-C364-A2, Release 11.2009
Flip the front plate forward (see Figure 3-4).
Figure 3-4 Open device
Note
Leaving the lower screws in the housing will make it easier to insert the front plate afterwards.
Caution
Do not strain the two ribbon cables that connect the front cover to the CPU board!
