Siemens SIMOCODE pro Operating Instructions

3ZX1012-0UF77-1BA1 3
Order No. I [A] Ø [mm] L1/L2/L3
3UF7110-1AA00-0 0.3 ... 3 A 7.5
3UF7111-1AA00-0 2.4 ... 25 A 7.5
3UF7112-1AA00-0 10 ... 100 A 14
3UF7113-1AA00-0 20 ... 200 A 25
Order No. I [A] A [mm²]/AWG L1/L2/L3
3UF7113-1BA00-0 20 ... 200 A
16 ... 95 mm²
AWG 6 to 3/0
3UF7114-1BA00-0 63 ... 630 A
50 ... 240 mm²
AWG 1/0 to 500 kcmil
3UF7114-1BA00-0
TORQUE: 7 ... 10.3 LB.IN
0,8 ... 1,2 Nm
2 x 0,5 ... 2,5 mm²/1 x 0,5 ... 4 mm²
2 x AWG 20 to 14/1 x AWG 20 to 12
2 x 0,5 ... 1,5 mm²/1 x 0,5 ... 2,5 mm²
2 x AWG 20 to 16/1 x AWG 20 to 14
PZ2/ Ø 5 ... 6 mm
10
10
145
6
149
67
88
32
125
147
122
Ø
1
1
25
48
Ø
1
1
U = 690 V max.
L1
L2
L3
N
M
~
3
L1 L2 L3
T1 T2 T3
L1 L2 L3
1)
1) Kurzschlussfeste Verdrahtung bzw. Leitungsschutz empfohlen
1) Short-circuit-proof wiring / cable protection recommended
1) Câblage résist. aux courts-circuits ou prot. des lignes récommandé
1) Cableado resistente a cortocircuitos o prot. de líneas recomendado
1) Consigliato cabaggio con protezione contro i cortocircuito o
1) Recomenda-se fiação resistente a curto-circuito ou proteção
protezione della linea
de condutores

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
