10.5.6 Terminal box 1XB7750
Figure 10-5 Terminal box 1XB7750 with standard cable entry
Table 10-5 Terminal box 1XB7750
Part Description Part Description
20.00 Complete terminal box with undrilled cable entry
plate
1
22.30 Connecting bar for main current
20.51 Cable entry plate with seal, undrilled 22.39 Neutral point connection
22.01 Saddle terminal, complete
1
You can only order the terminal box as part.
Spare parts
10.5 Machine parts
1MB5 SH 400/450
Operating Instructions, 05/2019, A5E45959221A 141
