Technical data
4.1 Technical data D4x5
SIMOTION D4x5
58 Manual, 02/2012
With CompactFlash cards, SIMOTION versions up to and including V4.1 SP1 incl. hotfixes
support a memory address of max. 512 MB. The limitation applies whether the card is being
used by SIMOTION runtime functions or for some other purpose such as storing documents.
Once there is more than 512 MB of data on the CompactFlash card, then the card is full as
far as SIMOTION runtime is concerned, i.e.:
● SIMOTION runtime cannot write any further data
● SIMOTION runtime cannot read data beyond the 512 MB range.
Note
Please note that
• The 1 GB CompactFlash cards with order number 6AU1400-2PA0*-0AA0 contain a
firmware as delivered that can only run on SIMOTION D4xx modules.
• The 1 GB CompactFlash cards with order number 6AU1400-*PA2*-0AA0 include
firmware that can only run on SIMOTION D4xx-2 modules.
It is also possible to use the 1 GB CompactFlash cards for SIMOTION D4xx-2 (order
number 6AU1400-*PA2*-0AA0) for SIMOTION D4xx modules by loading the latest boot
loader and the D4xx firmware. The reverse case is also possible. The CompactFlash card
must only be formatted as FAT or FAT16, and must not be formatted as FAT32 or NTFS.
Note that the CompactFlash cards for SIMOTION D4xx-2 can be formatted as FAT32.
Dimensions and weight
Table 4- 3 Dimensions and weight of a SIMOTION D4x5
Parameter SIMOTION D425/D435 SIMOTION D445 SIMOTION D445-1
Dimensions
W x H x D [mm]
(max. expansion)
• Excl. fastening
using spacers, no
fan or battery
modules
• Incl. fastening using
spacers, no fan or
battery modules
• 50 x 380 x 230
• 50 x 380 x 270
• Not possible
(spacers always
required)
• 50 x 380 x 270
• 50 x 380 x 230
• 50 x 380 x 270
Weight [g]
• Without packaging
• With packaging
• approx. 2600
• approx. 3100
• approx. 3500
• approx. 4000
• approx. 3100
• approx. 3600
