Technical data
4.1 Technical data D4x5
SIMOTION D4x5
Manual, 02/2012
59
Ambient conditions
Table 4- 4 D4x5 environmental requirements
Parameter Values
Permissible ambient temperature
• Storage and transport
• Operation
• -40° C ... +70° C
• 0° C to +55° C up to 2000 m above sea level
As of an altitude of 2000 m, the maximum ambient
temperature decreases by 7° C every 1000 m
Permissible relative humidity
(without condensation)
5 % ... 95 %
Installation altitude Max. 5000 m above sea level
1)
Organic/biological influences
• Storage
• Transport
• Operation
• Class 1B1 according to EN 60 721-3-1
• Class 2B1 according to EN 60 721-3-2
• Class 3B1 according to EN 60 721-3-3
Pollution degree 2 according to EN 60 664-1
Degree of protection according to EN 60529
(IEC 60529)
IP20
Atmospheric pressure 700 ... 1060 hPa
1)
The max. installation altitude for SINAMICS S120 drive components (motor modules, etc.) is 4000
m. Details can be found in the
SINAMICS S120 Control Units and Supplementary System
Components
Manual.
Shipping backup batteries
Backup batteries may only be shipped in the original packaging. No special authorization is
required to ship backup batteries. The lithium content is approximately 300 mg.
Note
The backup battery is classified as a hazardous substance, Class 9 in accordance with the
relevant air-freight transportation regulations.
For information on handling backup batteries, see Section Fan/battery module (Page 74).
Storage of backup batteries
Always store backup batteries in a cool and dry place. The maximum shelf life is 10 years.
