Interface characteristics
Table 4-12
Interface X23
Characteristic Type
Encoder interface ● TTL or HTL incremental encoders (with
adjustable parameters)
●
Absolute encoder SSI
Connector type 15-pin SUB-D connector
Encoder power supply 24 V DC/0.35 A or 5 V DC/0.35 A
Limit frequency 500 kHz
SSI baud rate 100 . . .250 kBaud
Resolution absolute position SSI 30 bits
Max. cable lengths
●
For TTL incremental encoder
● For HTL incremental encoder
● For SSI absolute encoder
● 100 m (bipolar signals only)
2)
● 100 m (for unipolar signals)
● 300 m (for bipolar signals)
1) 2)
● 100 m
1)
As of a cable length of 200 m, use a power supply cable with a cable cross-section
≥ 0.75 mm²!
2)
Signal cables twisted in pairs and shielded.
NOTICE
Destruction of the encoder electronics
Operation of a 5 V encoder on the 24 V encoder supply may result in the destruction of its
electronic components!
Make sure that you can operate the connected encoder on a 24 V power supply (e.g. HTL
encoder).
This setting can be set in the expert list of the drive in parameter p0400 and in the
following parameters.
Interfaces
4.6 Encoder interface (HTL/TTL/SSI)
SIMOTION D410
Manual, 04/2014 53
