Use prohibition
Without additional measures, SIMOTION D410 may not be used in
●
Locations with a high percentage of ionizing radiation
● Locations with extreme operating conditions, e.g.,
– Dust accumulation
– corrosive vapors or gases
● In systems, which require special monitoring, e.g.,
– Elevator installations
– Electrical systems in particularly hazardous rooms
An additional measure for using SIMOTION D410 can, for example, be installation in cabinets.
Mechanical ambient conditions
SIMOTION D410 meets the following standards for mechanical stress:
● Vibration load: DIN EN 60721-3-3, Class 3M4
● Shock load: DIN EN 60721-3-3, Class 3M4
● Free fall: DIN EN 60721-3-2, Class 2M1 and 2M2
● Toppling: DIN EN 60721-3-2, Class 2M1
The mechanical ambient conditions for SIMOTION D410 are listed in the following table in the
form of sinusoidal vibrations.
Table 7-17 Mechanical ambient conditions
Ambient conditions Operation Transport (in packaging)
Vibration tested in
accordance with DIN EN
60068-2-6
10 to 57 Hz: 0.35 mm
58 to 200 Hz: 50 m/s²
5 to 9 Hz: 3.5 mm
9 to 200 Hz: 10 m/s²
Shock resistance tested in
accordance with DIN EN
60068-2-27
10 g peak value, 6 ms duration
100
shocks in each axis vertical with respect
to each other
10 g peak value, 6 ms duration
100 shocks in each axis vertical with respect
to each other
Vibration reduction
If
SIMOTION D410 is subjected to larger shocks or vibrations, you must use suitable measures
to reduce the acceleration or the amplitude.
We recommend installation on shock-absorbing material (e.g. rubber-metal vibration dampers).
Technical data
7.8 Mechanical and climatic ambient conditions
SIMOTION D410
Manual, 04/2014 93
