Interface characteristics
Table 4-5
Ports X150 P1 to P3
Characteristic Type
Connector type RJ45 socket connector
Cable type PROFINET
Maximum cable length 100 m
Minimum transmission cycle 0.25 ms (D455‑2 DP/PN: 0.125 ms)
Autocrossing Yes
i.e. both crossed and uncrossed cables can be used
Dust protection filler plugs for
sealing unused PROFINET ports
5 filler plugs contained in the D4x5‑2 scope of delivery
Filler plugs (50 pcs) order number: 6SL3066‑4CA00‑0AA0
Interface assignments
Table 4-6
Assignment of the ports X150 P1 to P3
Representation Pin Name Description
1 TXP Transmit data +
2 TXN Transmit data -
3 RXP Receive data +
4 - Reserved, do not use
5 - Reserved, do not use
6 RXN Receive data -
7 - Reserved, do not use
8 - Reserved, do not use
Connectable devices
The following devices can be connected to the PROFINET IO interface:
●
PG/PC programming devices (communication with SIMOTION SCOUT / STEP 7)
● SIMATIC HMI devices
● SIMATIC controllers with PROFINET interface
● Distributed I/O
● Drive units with PROFINET IO interface (standard devices)
The SIMOTION D4x5‑2 DP/PN then assumes the role of a PROFINET IO controller and can
offer the following functions:
Interfaces
4.3 PROFINET IO interface (only for SIMOTION D4x5-2 DP/PN)
SIMOTION D4x5-2
56 Manual, 04/2014
