Siemens SIMOVERT MASTERDRIVES 6SE70 VC User Manual

Page 52 Version 1.0 March 1, 2000
B
A
C
D
Select “Function Block
Grafics” from the
Parameter Menu Bar
Select Function
N
umber 289
Zoom X 2
(with right Mouse click)
Set Trigger Binector in
U076.01
(i.e. U076.01 = 18 Din5)
Activate Block
U952.89 = 4
A
C
B
D
K431 can now be used to
trigger the Trace function
when Binector
(i.e. DIN 5) is
asserted hi
g
h.
To Configure the Trace to
Trigger with a Binector
follow instructions on this
p
a
g
e.
Function
Diagram
[720]
The block activated by Parameter
U952.89 is selected with 289.
