Siemens SIMOVERT MASTERDRIVES 6SE70 VC User Manual

Page 54 Version 1.0 March 1, 2000
A
B
C
Select Data Trace A
Click Data Set to
make it Active
Scale
Vertical Axis
B
Click and Drag
scale to shift it up
and down.
Y▲& Y ▼ to
change Scale
Scale
Horizontal Axis
C
Click and drag “T”
marker to shift
Horizontal Scale.
Move “[ ]” to
change scale
N
ote: Background can be change
d
with right mouse click.
Traces can be saved for reference.
