Parameterization 06.2006
6SE7087-6KP50 Siemens AG
8-44 Operating Instructions SIMOVERT MASTERDRIVES
Input in
P096
Motor order number
(MPRD)
Speed
n
n
[rpm]
Torque
M
n
[Nm]
Current
I
n
[A]
Number
of pole
pairs
177 1FK7105-5AC7 2000 37.0 16.0 4
178 1FK7105-5AF7 3000 26.0 18.0 4
179 to 199 for future applications
Explosion-proof
200 1FS6074-6AC71 2000 7.2 3.4 3
201 1FS6074-6AF71 3000 6.3 4.4 3
202 1FS6074-6AH71 4500 4.5 5.0 3
203 1FS6074-6AK71 6000 1.9 3.2 3
204 1FS6096-8AC71 2000 20.0 9.8 4
205 1FS6096-6AF71 3000 17.0 12.0 4
206 1FS6096-8AH71 4500 11.0 11.5 4
207 1FS6115-8AB73 1500 37.0 13.0 4
208 1FS6115-8AC73 2000 34.0 16.0 4
209 1FS6115-8AF73 3000 28.0 20.0 4
210 1FS6134-6AB73 1500 68.0 22.0 3
211 1FS6134-6AC73 2000 59.0 24.0 3
212 1FS6134-6AF73 3000 34.0 22.0 3
213 to
253
for future applications
Table 8-4 Motor list 1FK6 / 1FK7 / 1FT6 / 1FS6
Input in
P099
Motor order
number (MPRD)
Speed
n
n
[rpm]
Torque
M
n
[Nm]
Current
I
n
[A]
Number
of pole
pairs
1 1FW3201-1.H 300 300 22 14
2 1FW3202-1.H 300 500 37 14
3 1FW3203-1.H 300 750 59 14
4 1FW3204-1.H 300 1000 74 14
5 1FW3206-1.H 300 1500 117 14
6 1FW3208-1.H 300 2000 152 14
7 1FW3AH150 gen.
General template for customer-specific
1FW3
7
8 1FW3AH200 gen.
General template for customer-specific
1FW3
14
9 1FW3AH280 gen.
General template for customer-specific
1FW3
17
10 1FW3281-1.G 250 2400 153 17
Torque motors
1FW3
