Technical Data 06.2006
6SE7087-6KP50 Siemens AG
11-8 Operating Instructions SIMOVERT MASTERDRIVES
Designation Value
Order No. 6SE70... 24-7TP0 26-0TP0 27-2TP0
Rated voltage [V]
• Input
• Output
DC 510 (- 15 %) to 650 (+ 10 %)
3 AC 0 up to rated input voltage x 0.64
Rated frequency [Hz]
• Input
• Output
---
0 ... 400
Rated current [A]
• Input
• Output
55.9
47.0
70.2
59.0
85.7
72.0
Motor rated power [kW] 22.0 30.0 37.0
Auxiliary power supply [V] DC 24 (20 - 30)
Max. aux. current requirement [A]
• Standard version at 20 V
• Maximum version at 20 V
1.3
1.8
1.7
2.1
Pulse frequency fp [kHz] 2.5 to 10 kHz (see fig. "Derating curves")
Pulse frequencies <5 kHz and >8 kHz are available only with
Performance II units (60SE70_ _-_TP70)
Load class II to EN 60 146-1-1
Base load current [A] 0.91 x rated output current
Overload cycle time [s] 300
Overload current *) [A] 1.6 x rated output current
Overload duration [s] 30
Loses, cooling
Efficiency η (rated operation)
Power loss (fp = 6 kHz) [kW] 0.58 0.65 0.85
Cooling air requirement [m³/s] 0.041 0.061 0.061
Pressure drop ∆p [Pa] 30 30 30
Sound pressure levels, types of construction, dimensions, weights
Sound pressure level [dB(A)] 48 59 59
Dimensions [mm]
• Width
• Height
• Depth
180
360
260
180
360
260
180
360
260
Weight approx. [kg] 14.1 14.5 14.7
= 5 corresponds to MASTERDRIVES Motion Control
= 7 corresponds to MASTERDRIVES Motion Control Performance 2
*) With a 1.6-fold overload in field weakening, the torque quality is reduced
due to a ripple of 300 Hz.
Table 11-6 Technical data of inverter (part 3)
