Siemens simovert masterdrives - Dimension Drawings (135;180 mm wide)

10.98 Installation
Siemens AG 6SE7087-6KP50
SIMOVERT MASTERDRIVES Operating Instructions 5-3
Side view Front view
20 mm
220 mm
360 mm
Mounting surface
Cutouts
for M5 screws
414 mm
135 mm
250 mm
5.5 / 7.5 / 11 kW
180 mm
15 / 18.5 kW
Fig. 5-3 Dimension drawings for housings 135 mm and 180 mm wide
