12-pulse series connection
4.3 Commissioning
12-pulse applications
38 Compact User Manual, 09/2015, A5E34871844H
Parameter
Master
Slave or parallel devices
p51801
Amount of send data
0,4,8,12,16
The same as at the master
p51802 Number of power units
1)
≥ 2 ≥ 2
p51803
n+m mode
0
0
p51804[..] Send data Application-specific Application-specific
p51805
Bus terminator
0 or 1
2)
0 or 1
2)
p51806
Station address
Unique address
Unique address
p51807
Telegram failure time
0.1 s
0.1 s
p50082
Field operating mode
≠ 0
0 (no field)
p50076[..] Reduction in the rated unit DC cur-
rent
3)
Application-specific The same as on the master
p50078[..]
Rated value for supply voltage
Application-specific
The same as on the master
p50100 Rated motor current Rated motor current/half
the number of SINAMICS
DCMs
The same as on the master
p50101 Rated motor voltage Summed voltage (actual
armature voltage)
The same as at the master
1)
If the number of power units that are ready to operate for n+m operation is less than the value set in p51802, then fault
message F60044 is output, followed by shutdown (OFF2).
2)
= 1 at the two outermost units (= at the physical ends of the bus line)
= 0 on all of the other units
3)
Note: In conjunction with r50072[..], ensure that p50076[..] is correctly set, as described in the List Manual under
p50076[..].
