S5-95U, SINEC L2 Data Transmission by Accessing Layer 2 Services
8.2 Types and Characteristic Features of the Layer 2 Services
You have the following layer 2 services at your disposal:
Table 8-1. Layer 2 Services of the L2 Interface of the S5-95U
When Do You Use this
Layer 2 Service?
SDA
(Send Data with
Acknowledge)
Layer 2 Service Service can be Used if
the S5-95U is
Active Passive
Description in
Section
Active station sends data
to one active or passive
station.
SDN
(Send Data with No
Acknowledge)
Active station sends data
to one or more active or
passive stations.
