Start-Up, Tests, and Diagnostics S5-95U, SINEC L2
Table 3-8 lists the parameters, their meanings and their permissible range of values of the bus
parameter block for the STB display ‘Job completed without error’ (see detailed explanation of the
parameters in section 1.4).
Table 3-8. Bus Parameter Block Values for a READ_VALUE Confirmation
*
Bus parameters irrelevant for S5-95U user (for further explanations of the bus parameters, refer to
PROFIBUS Standards DIN 19245)
Byte Parameter Significance Value Range / Code
8 tln
(byte)
Address of the local station active stations 0 to 31
passive stations0 to 126
9 sta
(word)
Type of the local station 00H=passive
01H=active
10 hsa
(byte)
Highest active station address 1 to 126
11 bdr
(byte)
Baud rate 0 = 9.6 KBaud
1 = 19.2 KBaud
2 = 93.75 KBaud
3 = 187.5 KBaud
4 = 500 KBaud
5 = 1.5 MBaud
12 to
15
trt
(double word)
Target rotation time
In this time, the token should have
been passed once to every active
station.
256 to 1 048 320 bit times
16 & 17 st
(word)
Slot time
(initiator waits for reply frame)
34 to 4095 bit times
18 & 19 set
(byte)
Set-up time 0 to 494 bit times
20 & 21 STD1
(word)
Minimum station delay time 11 to 255 bit times
22 & 23 STD2
(word)
Maximum station delay time 35 to 1023 bit times
24 rtr*
(byte)
Number of call-up retries to a
remote, non-replying station
1 to 8
Default in the S5-95U: 1
25 gap*
(byte)
Gap update factor 2 to 255 in multiples of the
target rotation time
Default in the S5-95U: 20
