S5-95U, SINEC L2 Start-Up, Tests, and Diagnostics
Calling Up FB222 and Storing the Data with FMA Service TIME_TTH_READ
OB1 Explanation
. .
. .
0008 : L KH 0023 Load service_code in ACCUM and transfer to flag word
0009 : T FW 2 FW2
000A : JU FB 222 (see section 3.4.4)
000B NAME: AG95/FMA
000C REQ: F 1.0
If FMA service is requested, bit must be set.
000D CODE: FW 2 Enter type of service requested (here: 23
H
)
000E CONF: F 1.1 FB222 message: confirmation was received
0010 INDI: F 1.2 irrelevant
0011 FEHL: F 1.3 FB222 message: error occurred in PAFE or STB
. .
. .
0030 : BE
