Introduction 08/2005
1.2 Workstation
1
♥ Siemens AG, 2005. All rights reserved
1-20 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
1.2.2 Operator panels
You can use one of the following operator panels for the PCU:
OP 010
OP 010C
OP 010S
OP 012
OP 015
Operator panel OP 010
3
4
2
1
6
.
5
2
Operator panel OP 010
1 Screen
2 Screen keys
3 Horizontal softkey bar
4 Vertical softkey bar
5 Alphanumeric keypad
Correction/cursor pad with control keys and input key
6 USB interface
