08/2005 ShopTurn Functions
5.5 Millin
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-259
Multiple
edge >
¾ Press the "Milling", and "Multiple edge" soft keys.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Position You can select 3 different positions:
End face/End face C – Front
End face/End face C – Rear
End face Y – Front (only when Y axis exists)
Clamp/release spindle (for End face Y only)
The function must be set up by the machine manufacturer.
Machining
type
Roughing
Finishing
Finishing the edge
Chamfer
¬
Diameter of blank part mm
Z0
Reference point (abs) mm
N Number of edges (1, 2,.....)
SW Across the flats (alternative to L) – (for N = 1 or N = integer only) mm
L Edge length (alternative to SW) mm
α0
Angle of rotation of first edge with reference to X axis
α0 > 0: Multiple edge is rotated in CCW direction.
α0 < 0: Multiple edge is rotated in CW direction.
Degrees
FS1 Chamfer in XY plane (alternative to R1) – (3 edges or more)
R1 Rounding in XY plane (alternative to FS1) – (3 edges or more) mm
Z1 End point Z1 (abs or inc) – (for roughing and finishing only) mm
FS Chamfer width (abs) -- (for chamfer only) mm
ZFS Insertion depth of tool tip (abs or inc) -- (for chamfer only)
DZ Maximum depth infeed (Z direction) – (for roughing and finishing only) mm
DXY Maximum infeed in the XY plane – (for roughing and finishing only)
Plane infeed in %: Ratio of plane infeed (mm) to milling cutter diameter (mm)
mm
%
UZ Finishing allowance in depth -- (for roughing and finishing only) mm
UXY Finishing allowance in the plane – (for roughing and finishing only) mm
