ShopTurn Functions 08/2005
5.9 Machinin
g
with the counters
p
indle
5
♥ Siemens AG, 2005. All rights reserved
5-320 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Parkposition
XP
ZP
Complete:
WCS: The park position is entered into the workpiece coordinate system
MCS: The park position is entered in the machine coordinate system; the teaching
of the park position and the angular offset is possible
Park position of tool in X direction (abs)
Park position of tool in Z direction (abs)
mm
mm
Rinse chuck
S
Direction of
rotation
Gripping:
Rinse counterspindle chuck or not
Spindle speed (main spindle and counterspindle)
Direction of rotation (main spindle and counterspindle):
Direction of rotation clockwise (right)
Direction of rotation counterclockwise (left)
No spindle rotation
rpm
α1
Z1
ZR
FR
Fixed stop
Angular offset of counterspindle on gripping
Transfer position (abs.)
Position at which traversal at reduced feedrate starts (abs or inc)
Reduced feedrate
Yes: The counterspindle comes to a halt a specified distance from the
transfer position Z1 and then traverses at the specified feedrate as far as
the limit stop.
No: The counterspindle traverses to the transfer position Z1.
Degrees
mm
mm
mm/min
Pull blank
F
Parting cycle
Pulling:
Yes: Pull blank one blank length (preparation for next
workpiece)
No: Do not pull blank
Feedrate for pulling
Yes: The workpiece is parted after it has been pulled out.
No: No automatic parting.
mm/min
Work offset
ZnW
ZV
Rear side:
Work offset in which the coordinate system, which was shifted according to ZW and
by ZV as well as mirrored in Z, must be saved.
Machining position for special axis (abs.); machine coordinating system
Workpiece zero offset in Z direction (inc, the sign is also evaluated)
mm
mm
