Siemens SINUMERIK 808D ADVANCED Training Manual

Programming and Operating — Turning Page 6 808D ADVANCED
Preparation
s
MCP
Moving axis
Axis movement
The 808D machine control
panel (MCP) is used to
control manual operation of
the axis.
The machine can be moved
with the appropriate keys.
MCP
OEM
keys
OEM key
The 808D machine control
panel (MCP) is used to
control OEM machine
functions.
The machine functions can
be activated with the appro-
priate keys.
User
interface
808D ADVANCED
(PPU) has eight
vertical softkeys
(abbr. SK) on the
right of the screen.
These SK’s can be
activated with the
corresponding button
(located on the right).
808D ADVANCED (PPU) has eight horizontal SK’s on the bottom
of the screen. These SK’s can be activated with the corresponding
button (located below).

Siemens SINUMERIK 808D ADVANCED Specifications

General

Brand	Siemens
Model	SINUMERIK 808D ADVANCED
Category	Control Unit
Language	English
