Siemens SINUMERIK 808D ADVANCED Training Manual

808D ADVANCED Page 5 Programming and Operating — Turning
Preparation
s
Unit Description
This unit describes the 808D ADVANCED PPU and MCP functionality, the
coordinate system of a turning machine and how to enter passwords to
access the system.
Unit Content
PPU
Function of
keyboard
MCP mode
Changing
MCP
Moving
axis
MCP
OEM
keys
Machine
coordinate
system
User
interface
Passwords
PPU
Function of
keyboard
The 808D ADVANCED
panel processing unit
(PPU) is used to input
data to the CNC and to
navigate to operating
areas of the system.
MCP mode
Changing
Mode Navigation
The 808D machine
control panel (MCP) is
used to select the
machine operating
mode :
JOG - MDA - AUTO
Menu navigation
Operating area
navigation
End
