Siemens SINUMERIK 808D ADVANCED Training Manual

Programming and Operating — Turning Page 98 808D ADVANCED
Sample
Programs
s
Machining Process
N200 G0X100Z200
N210 T1 F400 G94
N220 G0 X50 Z60 SPOS=0
N230 SETMS(2)
N240 M3 S2000
N250 TRANSMIT
N260 G90 G17
N270 DIAMOF
N280 G1 Z-10 F100
N290 G1 X8 Y0 G42 RND=2
N300 X4Y6.928
N310 RND=2
N320 X-4Y6.928 RND=2
N330 X-8 Y0
N340 RND=2
N350 X-4Y-6.928
N360 RND=2
N370 X4Y-6.928
N380 RND=2
N390 X8 Y0
N400 RND=2
N410 G40 G0 Z40 RND=2
N420 M5
N430 TRAFOOF
N440 SETMS
N450 G54 G18 G0 X50 Z60
N460 Z30
N470 M30
N200
N210 Feedrate in mm/min 400
N220 Rotational positioning 0 deg
N230 Set the second spindle as main
spindle
N240
N250 Activate TRANSMIT function
N260 Activate G17 plane
N270 Deactivate dim programming
N280
N290 Activate TRC G42, radius 2 mm
N300
N310
N320
N330
N340
N350
N360
N370
N380
N390
N400
N410 Cancel TRC，radius 2mm
N420
N430 Deactivate TRANSMIT function
N440 Set the first spindle as main spindle
N450
N460
N470
PART_SUB_4.SPF
G18 G90 DIAMON
G0 Z0 X-.5
G1 X20
Z-35.5
X30 CHR=1
Z-50
X36 CHR=1
Z-75
X46
M2 ; /* end of contour */
Sub program
