Siemens SINUMERIK 808D Installation Manual

System overview
Electrical Installation Manual
12 Operating Instructions, 12/2014, 6FC5397-2EP10-0BA0
Legend
Name
Order number
1) PPU141.1, turning 6FC5370-1AT00-0AA0 (English)
6FC5370-1AT00-0CA0 (Chinese)
PPU141.1, milling 6FC5370-1AM00-0AA0 (English)
6FC5370-1AM00-0CA0 (Chinese)
2) MCP 6FC5303-0AF35-0AA0 (English)
6FC5303-0AF35-0CA0 (Chinese)
3) Setpoint cable PPU141.1 to CPM60.1 6FC5548-0BA00-1AF0 (5 m)
6FC5548-0BA00-1AH0 (7 m)
6FC5548-0BA00-1BA0 (10 m)
4) SINAMICS V60 Controlled Power Module
(CPM60.1)
6SL3210-5CC14-0UA0 (4 A)
6SL3210-5CC16-0UA0 (6 A)
6SL3210-5CC17-0UA0 (7 A)
6SL3210-5CC21-0UA0 (10 A)
5) 1FL5 Motor 1FL5060-0AC21-0AA0 (4 Nm, with key,
without brake)
1FL5060-0AC21-0AG0 (4 Nm, without key,
without brake)
1FL5062-0AC21-0AA0 (6 Nm, with key,
without brake)
1FL5062-0AC21-0AG0 (6 Nm, without key,
without brake)
1FL5064-0AC21-0AA0 (7.7 Nm, with key,
without brake)
1FL5064-0AC21-0AG0 (7.7 Nm, without key,
without brake)
1FL5066-0AC21-0AA0 (10 Nm, with key,
without brake)
1FL5066-0AC21-0AG0 (10 Nm, without key,
without brake)
1FL5060-0AC21-0AB0 (4 Nm, with key,
with brake)
1FL5060-0AC21-0AH0 (4 Nm, without key,
with brake)
1FL5062-0AC21-0AB0 (6 Nm, with key,
with brake)
1FL5062-0AC21-0AH0 (6 Nm, without key,
with brake)
1FL5064-0AC21-0AB0 (7.7 Nm, with key,
with brake)
1FL5064-0AC21-0AH0 (7.7 Nm, without key,
with brake)
1FL5066-0AC21-0AB0 (10 Nm, with key,
with brake)
