Siemens SINUMERIK 808D Installation Manual

System overview
Electrical Installation Manual
Operating Instructions, 12/2014, 6FC5397-2EP10-0BA0
13
Legend
Name
Order number
1FL5066-0AC21-0AH0 (10 Nm, without key,
with brake)
6) Setpoint cable PPU141.1 to inverter or
servo spindle drive
6FC5548-0BA05-1AF0 (5 m)
6FC5548-0BA05-1AH0 (7 m)
6FC5548-0BA05-1BA0 (10 m)
7) Power cable (unshielded) 6FX6002-5LE00-1AF0 (5 m)
6FX6002-5LE00-1BA0 (10 m)
8) Brake cable (unshielded) 6FX6002-2BR00-1AF0 (5 m)
6FX6002-2BR00-1BA0 (10 m)
9) Encoder cable (shielded) 6FX6002-2LE00-1AF0 (5 m)
6FX6002-2LE00-1BA0 (10 m)
10) Inverter or servo spindle drive From Siemens or a third-party manufacturer
System structure
The structure of the SINUMERIK 808D control system is shown as follows:
●
CNC Unit
– Panel Processing Unit (PPU)
– Machine Control Panel (MCP)
– Setpoint cable to SINAMICS V60
– Setpoint cable to the spindle
●
Drive unit
– SINAMICS V60 (for controlling feed axes)
– 1FL5 motor
– Power cable
– Encoder cable
– Brake cable (for motors with brake)
– Inverter or servo spindle drive (for controlling the spindle)
– Spindle motor
– Spindle encoder
●
Electronic handwheels
A maximum of two handwheels can be connected
