Connecting
3.3 Connecting the interfaces on the PPU
Electrical Installation Manual
Operating Instructions, 12/2014, 6FC5397-2EP10-0BA0
25
Table 3- 7 Pin assignment of X301 (DISTRIBUTED I/O 1)
1 MEXT External ground 26 I5.7 Digital input
2 +24V +24V output
1)
27 - Not assigned
3 I3.0 Digital input 28 - Not assigned
4 I3.1 Digital input 29 - Not assigned
5 I3.2 Digital input 30 - Not assigned
6 I3.3 Digital input 31 Q2.0 Digital output
7 I3.4 Digital input 32 Q2.1 Digital output
8 I3.5 Digital input 33 Q2.2 Digital output
9 I3.6 Digital input 34 Q2.3 Digital output
10 I3.7 Digital input 35 Q2.4 Digital output
11 I4.0 Digital input 36 Q2.5 Digital output
12 I4.1 Digital input 37 Q2.6 Digital output
13 I4.2 Digital input 38 Q2.7 Digital output
14 I4.3 Digital input 39 Q3.0 Digital output
15 I4.4 Digital input 40 Q3.1 Digital output
16 I4.5 Digital input 41 Q3.2 Digital output
17 I4.6 Digital input 42 Q3.3 Digital output
18 I4.7 Digital input 43 Q3.4 Digital output
19 I5.0 Digital input 44 Q3.5 Digital output
20 I5.1 Digital input 45 Q3.6 Digital output
21 I5.2 Digital input 46 Q3.7 Digital output
22 I5.3 Digital input 47 +24V +24V Input
23 I5.4 Digital input 48 +24V +24V Input
24 I5.5 Digital input 49 +24V +24V Input
25 I5.6 Digital input 50 +24V +24V Input
