Connecting
3.3 Connecting the interfaces on the PPU
Electrical Installation Manual
26 Operating Instructions, 12/2014, 6FC5397-2EP10-0BA0
Table 3- 8 Pin assignment of X302 (DISTRIBUTED I/O 2)
1 MEXT External ground 26 I8.7 Digital input
2 +24V +24V output
1)
27 - Not assigned
3 I6.0 Digital input 28 - Not assigned
4 I6.1 Digital input 29 - Not assigned
5 I6.2 Digital input 30 - Not assigned
6 I6.3 Digital input 31 Q4.0 Digital output
7 I6.4 Digital input 32 Q4.1 Digital output
8 I6.5 Digital input 33 Q4.2 Digital output
9 I6.6 Digital input 34 Q4.3 Digital output
10 I6.7 Digital input 35 Q4.4 Digital output
11 I7.0 Digital input 36 Q4.5 Digital output
12 I7.1 Digital input 37 Q4.6 Digital output
13 I7.2 Digital input 38 Q4.7 Digital output
14 I7.3 Digital input 39 Q5.0 Digital output
15 I7.4 Digital input 40 Q5.1 Digital output
16 I7.5 Digital input 41 Q5.2 Digital output
17 I7.6 Digital input 42 Q5.3 Digital output
18 I7.7 Digital input 43 Q5.4 Digital output
19 I8.0 Digital input 44 Q5.5 Digital output
20 I8.1 Digital input 45 Q5.6 Digital output
21 I8.2 Digital input 46 Q5.7 Digital output
22 I8.3 Digital input 47 +24V +24V Input
23 I8.4 Digital input 48 +24V +24V Input
24 I8.5 Digital input 49 +24V +24V Input
25 I8.6 Digital input 50 +24V +24V Input
1)
Make sure that the current at pin 2 of X301 or X302 does not exceed the maximum current
I
out
= 0.25 A; otherwise, the controller could be destroyed.
The 24 V power supply must be protective extra low voltage in accordance with EN60204-
1, Section 6.4, PELV (with M ground).
