Operation 08.02
2.1 O
p
erator
p
anels
2
© Siemens AG, 2002. All rights reserved
2-20 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
Slimline operator panel
OP 010S
1
A3
A4
A2
8
A2
Operator panel OP 010S
With CNC full keyboard
OP 032S
Tool
Offset
Program
Program
Manager
Alarm
5
6
7
CNC keyboard OP 032S
1 Monitor
2 Monitor keys
3 Horizontal soft key menu
4 Vertical soft key menu
5 Alpha pad
6 Correction/cursor pad with control keys
7 Numeric pad
8 USB interface
