3
Preparatory Functions for Machining 08.02
3.2 Setu
p
3
© Siemens AG, 2002. All rights reserved
3-44 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
3.2 Setup
Function
In setup mode, you move the axes with
• the direction and JOG keys or
• the handwheels.
X+
Z+
Sequence of operations
Any operating mode
Start lamp is off or Stop lamp is on
(axes are not in motion)
Select axis direction
Trigger a movement with the JOG keys, e.g. with rapid traverse
Rapid traverse
Normal speed
Creep speed
Fine speed
