Siemens SINUMERIK 840D sl Ctrl-Energy User Manual

Auxiliary system Start of the data structure End of the data structure
Auxiliary system 7 (n=240) DB1001.DBB340 DB1001.DBB379
Auxiliary system 8 (n=280) DB1001.DBB380 DB1001.DBB419
Auxiliary system 9 (n=320) DB1001.DBB420 DB1001.DBB459
Auxiliary system 10 (n=360) DB1001.DBB460 DB1001.DBB499
DB1001
Name: SentronPac
Signal
direction
Meaning Identifier Format
DB1001.DBX(100+n).0 PLC ->
GP/HMI
GP calculates the energy/
power of the auxiliary sys‐
tem
ProcessAux BOOL
DB1001.DBX(100+n).1 PLC ->
GP/HMI
Actual value update ReadEnergy BOOL
DB1001.DBX(100+n).2 PLC ->
GP/HMI
Measurement in progress MeasACT BOOL
DB1001.DBX(100+n).3 PLC ->
GP/HMI
1: Differential values are
written to the variables for
the measurement end
0: Absolute values are
written to the variables for
the measurement start
and measurement end
MeasMode BOOL
DB1001.DBX(100+n).4 PLC ->
GP/HMI
1: Energy
0: Power
InputMode BOOL
DB1001.DBX(100+n).7 PLC ->
GP/HMI
Delete data structure ResetAux BOOL
DB1001.DBD(104+n) PLC ->
GP/HMI
Active power or active en‐
ergy of the auxiliary sys‐
tem
ActivePowerAux REAL
DB1001.DBD(108+n) GP ->
HMI
Active energy drawn by
the auxiliary system in
kWh
ActiveEnAux REAL
DB1001.DBD(112+n) GP ->
HMI
Active energy supplied by
the auxiliary system in
kWh
ReActiveEnAux REAL
DB1001.DBD(116+n) GP ->
HMI
Active energy drawn by
the auxiliary system at
the measurement start in
kWh
ActiveEnAuxMeasON REAL
DB1001.DBD(120+n) GP ->
HMI
Active energy supplied by
the auxiliary system at
the measurement start in
kWh
ReActiveEnAuxMeasON REAL
Ctrl-E Analysis
3.3 Commissioning the PLC for Ctrl-E Analysis
Ctrl-Energy
26 System Manual, 01/2015, 6FC5397-0EP40-5BA2
