DB1001
Name: SentronPac
Signal
direction
Meaning Identifier Format
DB1001.DBD48 GP -> HMI Imported active ener‐
gy in kWh month to
HMI
ActiveEnergyMonth REAL
DB1001.DBD52 GP -> HMI Exported active ener‐
gy in kWh month to
HMI
ReactiveEnergyMonth REAL
DB1001.DBD56 GP -> HMI Imported active ener‐
gy in kWh previous
month to HMI
ActiveEnergyPrevMonth REAL
DB1001.DBD60 GP -> HMI Exported active ener‐
gy in kWh previous
month to HMI
ReactiveEnergyPrevMonth REAL
DB1001.DBD64 GP -> HMI Imported active ener‐
gy in kWh year to HMI
ActiveEnergyYear REAL
DB1001.DBD68 GP -> HMI Exported active ener‐
gy in kWh year to HMI
ReactiveEnergyYear REAL
DB1001.DBD72 GP -> HMI Imported active ener‐
gy in kWh previous
year to HMI
ActiveEnergyPrevYear REAL
DB1001.DBD76 GP -> HMI Exported active ener‐
gy in kWh previous
year to HMI
ReactiveEnergyPrevYear REAL
DB1001.DBB96 PLC -> HMI Presentation of the en‐
ergy consumption in
the status display
ProductionAct Byte
Note
Evaluation of the energy consumption of the complete machine
If you have installed SENTRON PAC in the main circuit of the machine or SENTRON PAC
evaluates the energy consumption of the complete machine, set bit DB1001.DBX0.1 to 1.
As a consequence, in the display for Ctrl-E Analysis, the line "SentronPAC" is removed and
the measured value of the SENTRON PAC is entered into the line "Total machine".
Data block for auxiliary systems
Up to 10 auxiliary systems are supported by the data block. A data structure is defined for each
auxiliary system. In order to display the energy/power of an auxiliary system in the HMI, bit 0
of the first byte of the data structure must be set.
Auxiliary system Start of the data structure End of the data structure
Auxiliary system 1 (n=0) DB1001.DBB100 DB1001.DBB139
Auxiliary system 2 (n=40) DB1001.DBB140 DB1001.DBB179
Auxiliary system 3 (n=80) DB1001.DBB180 DB1001.DBB219
Auxiliary system 4 (n=120) DB1001.DBB220 DB1001.DBB259
Auxiliary system 5 (n=160) DB1001.DBB260 DB1001.DBB299
Auxiliary system 6 (n=200) DB1001.DBB300 DB1001.DBB339
Ctrl-E Analysis
3.3 Commissioning the PLC for Ctrl-E Analysis
Ctrl-Energy
System Manual, 01/2015, 6FC5397-0EP40-5BA2 25
