Status signals
DB1000
DBX4.0 Energy-saving profile is active
DBX4.1 Prewarning limit T1 reached
Actual values
DB1000
DBW6 Actual value T
1
DBW8 Actual value T
2
4.1.5.2 Signals for parameterization
Retentive parameterization data.
Effectiveness (HMI → PLC)
DB1000
DBX 10.0 Energy-saving profile configured
DBX 10.1 Disable energy-saving profile
Masking (HMI → PLC)
DB1000
DBX 11.0 Keyboard has been used
DBX 11.1 Data transfer active
DBX 11.2 Screen change active
DBX 12.0 Machine control panel used
DBX 13.0 NCK channel 1
DBX 13.1 NCK channel 2
DBX 13.2 NCK channel 3
DBX 13.3 NCK channel 4
DBX 13.4 NCK channel 5
DBX 13.5 NCK channel 6
DBX 13.6 NCK channel 7
DBX 13.7 NCK channel 8
DBX 14.0 NCK channel 9
DBX 14.1 NCK channel 10
DBX 15.0 Master computer prohibits*
DBX 15.1 PLC user program signal prohibits*
*prohibits changing into the energy-saving mode
Ctrl-E Profiles
4.1 Commissioning the PLC for Ctrl-E Profiles
Ctrl-Energy
System Manual, 01/2015, 6FC5397-0EP40-5BA2 45
