DB1001
Name: SentronPac
Signal
direction
Meaning Identifier Format
DB1001.DBX0.2 PLC -> HMI Imported active ener‐
gy is read from SEN‐
TRON PAC
FeedInEnergyReadSP BOOL
DB1001.DBX0.3 PLC -> HMI Exported active ener‐
gy is read from SEN‐
TRON PAC
FeedBackEnergyReadSP BOOL
DB1001.DBX1.0 PLC -> GP Measuring request to
PLC basic program
MeasAuto BOOL
DB1001.DBX2.0 HMI -> GP Measurement is run‐
ning
MeasAct BOOL
DB1001.DBX3.0 PLC -> HMI Power display shown
in status display
EStateOn BOOL
DB1001.DBD4 PLC -> HMI Manual value ManualValue REAL
DB1001.DBD8 GP -> HMI Total active power ActivePowerItem REAL
DB1001.DBD12 MeasAuto
== 0:
PLC -> HMI
MeasAuto
== 1:
GP -> HMI
Measured imported
active energy in kWh
to HMI
ActiveEnergyItem REAL
DB1001.DBD16 MeasAuto
== 0:
PLC -> HMI
MeasAuto
== 1:
GP -> HMI
Measured exported
active energy in kWh
to HMI
ReactiveEnergyItem REAL
DB1001.DBD20 PLC -> GP Total active power
in watts from SEN‐
TRON
ActivePowerSentron REAL
DB1001.DBD24 PLC -> GP Imported active ener‐
gy at tariff 1 (F) in Wh
from SENTRON
ActiveEnergySentron REAL
DB1001.DBD28 PLC -> GP Exported active ener‐
gy at tariff 1 (F) in Wh
from SENTRON
ReactiveEnergySentron REAL
DB1001.DBD32 GP -> HMI Imported active ener‐
gy in kWh current day
to HMI
ActiveEnergyDay REAL
DB1001.DBD36 GP -> HMI Exported active ener‐
gy in kWh current day
to HMI
ReactiveEnergyDay REAL
DB1001.DBD40 GP -> HMI Imported active ener‐
gy in kWh previous
day to HMI
ActiveEnergyPrevDay REAL
DB1001.DBD44 GP -> HMI Exported active ener‐
gy in kWh previous
day to HMI
ReactiveEnergyPrevDay REAL
Ctrl-E Analysis
3.3 Commissioning the PLC for Ctrl-E Analysis
Ctrl-Energy
24 System Manual, 01/2015, 6FC5397-0EP40-5BA2
