PRESS(VS4)
LM("maske_xxx","xxx.com")
END_PRESS
HS7=("Start YYY")
PRESS(HS7)
LM("maske_yyy","yyy.com")
END_PRESS
//END
These start calls directly access the specified screen forms of the relevant *.com files. A start
softkey in these particular *.com files can be omitted.
● Save the project files "xxx.com", "yyy.com" and "aufruf.com" in the following directory: oem
\sinumerik\hmi\proj\.
References
Additional information on the design and configuration of user interfaces is provided in the
following references on SINUMERIK Integrate Run MyScreens (Easy Screen):
Programming Manual Easy Screen (BE2); SINUMERIK 840D sl
User know-how
7.1 Commissioning user screen forms
